Boîtier PC Darkflash A290 ATX noir

The Darkflash A290 computer case in black is a mid-tower chassis designed for ATX, M-ATX and ITX builds. It includes a tempered glass side panel for component visibility and ships with three CL6 fans preinstalled. The case supports multiple drive mounts and provides front-panel connectivity including USB 3.0, USB 2.0 and a headphone/speaker output.

Advantages

The A290 offers a balance of component compatibility and cooling options in a compact 320x190x433mm footprint. Its tempered glass side panel highlights illuminated components while a removable dust filter simplifies maintenance. Preinstalled CL6 fans and support for up to five 120mm fans or a 240mm radiator enable effective airflow for gaming or demanding workloads.

Suitable for

• Gaming PC builds with ATX, micro‑ATX or mini‑ITX motherboards
• Compact workstations needing efficient cooling
• Users who want a showcase case with tempered glass side panel

Key specifications

• Brand: Darkflash; Model: A290; Color: Black
• Supported motherboard formats: ATX, M-ATX, ITX
• Dimensions: 320 x 190 x 433 mm
• Side panel: Tempered glass
• Drive bays: HDD x1, SSD x1
• Expansion slots: 7
• Max GPU length: 260 mm; Max CPU cooler height: 160 mm
• Power supply position: Bottom-mounted
• Cooling options: Front 2×120 mm, Rear 1×120 mm, Top 2×120 mm; supports up to 5×120 mm fans or 240 mm radiator
• Front panel connectors: USB 3.0 ×1, USB 2.0 ×2, Headphone/speaker output, Power, Reset

How to use

Install a compatible ATX, M-ATX or ITX motherboard on the interior standoffs, mount the power supply at the bottom, and fit storage drives into the designated HDD and SSD mounts. Install the graphics card up to 260 mm in length in the PCIe expansion slots and fit a CPU cooler under 160 mm in height. Configure airflow by installing additional 120 mm fans in the front, top and rear positions or by mounting a 240 mm liquid cooler in the supported location.

Recommendations

For best cooling performance, maintain unobstructed airflow by routing cables behind the motherboard tray and using the included three CL6 fans together with at least one additional intake fan at the front. Regularly remove and clean the dust filter to preserve airflow and component longevity.
